Linux下文件同步神器rsync的简易用法

使用rsync的原因

博主因为有很多台服务器使用了证书，都是一个域名下的二级域名，如果每台服务器都去使用acme去申请一次证书，觉得实在浪费lts的资源，趁此机会，研究一下文件同步神器rsync，实现每次证书申请的服务器对证书更新后，会自动将新的证书自动同步到其它服务器中，供其他服务器使用。

操作步骤：

申请证书

首先在证书申请服务器1.1.1.1上申请证书，可参看这篇文章：

使用ACME自动申请证书

博主使用的是NPM(Nginx proxy manager)，证书目录会有所不同，注意进行替换。

安装rsync

博主使用的debian系统，其他系统自行查询命令：

apt install -y rsync

 使用rsync进行本地文件的同步

我需要将npm申请的证书，同步到本机的另外一个文件夹的位置

• npm申请证书的位置：/root/Docker/npm/letsencrypt/archive/npm-4/
• 本地其他服务需要使用证书的位置：/root/Docker/XR/config/cert/

使用命令：rsync [-参数] [源文件] [目标文件]

rsync -a /root/Docker/npm/letsencrypt/archive/npm-4/ /root/Docker/XR/config/cert/

• -a 使用增量更新和同步的方式

 使用rsync同步推送文件到远端

• 服务器A中的证书位置：/root/Docker/npm/letsencrypt/archive/npm-4/
• 服务器B中待同步证书位置：/root/Docker/XR/config/cert/
• 服务器B的SSH连接参数：
  • 用户名：root
  • 密码：pass123
  • 端口：2222

首先在服务器A和B中都安装rsync。

再使用命令将服务器A中的目录同步到服务器B中，在服务器A中执行命令：

rsync -av -e "ssh -p 2222" /root/Docker/npm/letsencrypt/archive/npm-4/ root@2.2.2.2:/root/Docker/XR/config/cert/
#然后按照提示，输入远端服务器B的root用户的密码，本例中为pass123

• -v 显示同步日志
• -e "ssh -p 2222" 增加参数，连接远端服务器ssh端口为2222
• root@2.2.2.2 连接远端服务器用户名为root，服务器地址为2.2.2.2

rsync帮助文件

rsync  version 3.2.3  protocol version 31
Copyright (C) 1996-2020 by Andrew Tridgell, Wayne Davison, and others.
Web site: https://rsync.samba.org/
Capabilities:
    64-bit files, 64-bit inums, 64-bit timestamps, 64-bit long ints,
    socketpairs, hardlinks, hardlink-specials, symlinks, IPv6, atimes,
    batchfiles, inplace, append, ACLs, xattrs, optional protect-args, iconv,
    symtimes, prealloc, stop-at, no crtimes
Optimizations:
    SIMD, asm, openssl-crypto
Checksum list:
    xxh128 xxh3 xxh64 (xxhash) md5 md4 none
Compress list:
    zstd lz4 zlibx zlib none

rsync comes with ABSOLUTELY NO WARRANTY.  This is free software, and you
are welcome to redistribute it under certain conditions.  See the GNU
General Public Licence for details.

rsync is a file transfer program capable of efficient remote update
via a fast differencing algorithm.

Usage: rsync [OPTION]... SRC [SRC]... DEST
  or   rsync [OPTION]... SRC [SRC]... [USER@]HOST:DEST
  or   rsync [OPTION]... SRC [SRC]... [USER@]HOST::DEST
  or   rsync [OPTION]... SRC [SRC]... rsync://[USER@]HOST[:PORT]/DEST
  or   rsync [OPTION]... [USER@]HOST:SRC [DEST]
  or   rsync [OPTION]... [USER@]HOST::SRC [DEST]
  or   rsync [OPTION]... rsync://[USER@]HOST[:PORT]/SRC [DEST]
The ':' usages connect via remote shell, while '::' & 'rsync://' usages connect
to an rsync daemon, and require SRC or DEST to start with a module name.

Options
--verbose, -v            increase verbosity
--info=FLAGS             fine-grained informational verbosity
--debug=FLAGS            fine-grained debug verbosity
--stderr=e|a|c           change stderr output mode (default: errors)
--quiet, -q              suppress non-error messages
--no-motd                suppress daemon-mode MOTD
--checksum, -c           skip based on checksum, not mod-time & size
--archive, -a            archive mode is -rlptgoD (no -A,-X,-U,-N,-H)
--no-OPTION              turn off an implied OPTION (e.g. --no-D)
--recursive, -r          recurse into directories
--relative, -R           use relative path names
--no-implied-dirs        don't send implied dirs with --relative
--backup, -b             make backups (see --suffix & --backup-dir)
--backup-dir=DIR         make backups into hierarchy based in DIR
--suffix=SUFFIX          backup suffix (default ~ w/o --backup-dir)
--update, -u             skip files that are newer on the receiver
--inplace                update destination files in-place
--append                 append data onto shorter files
--append-verify          --append w/old data in file checksum
--dirs, -d               transfer directories without recursing
--mkpath                 create the destination's path component
--links, -l              copy symlinks as symlinks
--copy-links, -L         transform symlink into referent file/dir
--copy-unsafe-links      only "unsafe" symlinks are transformed
--safe-links             ignore symlinks that point outside the tree
--munge-links            munge symlinks to make them safe & unusable
--copy-dirlinks, -k      transform symlink to dir into referent dir
--keep-dirlinks, -K      treat symlinked dir on receiver as dir
--hard-links, -H         preserve hard links
--perms, -p              preserve permissions
--executability, -E      preserve executability
--chmod=CHMOD            affect file and/or directory permissions
--acls, -A               preserve ACLs (implies --perms)
--xattrs, -X             preserve extended attributes
--owner, -o              preserve owner (super-user only)
--group, -g              preserve group
--devices                preserve device files (super-user only)
--copy-devices           copy device contents as regular file
--specials               preserve special files
-D                       same as --devices --specials
--times, -t              preserve modification times
--atimes, -U             preserve access (use) times
--open-noatime           avoid changing the atime on opened files
--crtimes, -N            preserve create times (newness)
--omit-dir-times, -O     omit directories from --times
--omit-link-times, -J    omit symlinks from --times
--super                  receiver attempts super-user activities
--fake-super             store/recover privileged attrs using xattrs
--sparse, -S             turn sequences of nulls into sparse blocks
--preallocate            allocate dest files before writing them
--write-devices          write to devices as files (implies --inplace)
--dry-run, -n            perform a trial run with no changes made
--whole-file, -W         copy files whole (w/o delta-xfer algorithm)
--checksum-choice=STR    choose the checksum algorithm (aka --cc)
--one-file-system, -x    don't cross filesystem boundaries
--block-size=SIZE, -B    force a fixed checksum block-size
--rsh=COMMAND, -e        specify the remote shell to use
--rsync-path=PROGRAM     specify the rsync to run on remote machine
--existing               skip creating new files on receiver
--ignore-existing        skip updating files that exist on receiver
--remove-source-files    sender removes synchronized files (non-dir)
--del                    an alias for --delete-during
--delete                 delete extraneous files from dest dirs
--delete-before          receiver deletes before xfer, not during
--delete-during          receiver deletes during the transfer
--delete-delay           find deletions during, delete after
--delete-after           receiver deletes after transfer, not during
--delete-excluded        also delete excluded files from dest dirs
--ignore-missing-args    ignore missing source args without error
--delete-missing-args    delete missing source args from destination
--ignore-errors          delete even if there are I/O errors
--force                  force deletion of dirs even if not empty
--max-delete=NUM         don't delete more than NUM files
--max-size=SIZE          don't transfer any file larger than SIZE
--min-size=SIZE          don't transfer any file smaller than SIZE
--max-alloc=SIZE         change a limit relating to memory alloc
--partial                keep partially transferred files
--partial-dir=DIR        put a partially transferred file into DIR
--delay-updates          put all updated files into place at end
--prune-empty-dirs, -m   prune empty directory chains from file-list
--numeric-ids            don't map uid/gid values by user/group name
--usermap=STRING         custom username mapping
--groupmap=STRING        custom groupname mapping
--chown=USER:GROUP       simple username/groupname mapping
--timeout=SECONDS        set I/O timeout in seconds
--contimeout=SECONDS     set daemon connection timeout in seconds
--ignore-times, -I       don't skip files that match size and time
--size-only              skip files that match in size
--modify-window=NUM, -@  set the accuracy for mod-time comparisons
--temp-dir=DIR, -T       create temporary files in directory DIR
--fuzzy, -y              find similar file for basis if no dest file
--compare-dest=DIR       also compare destination files relative to DIR
--copy-dest=DIR          ... and include copies of unchanged files
--link-dest=DIR          hardlink to files in DIR when unchanged
--compress, -z           compress file data during the transfer
--compress-choice=STR    choose the compression algorithm (aka --zc)
--compress-level=NUM     explicitly set compression level (aka --zl)
--skip-compress=LIST     skip compressing files with suffix in LIST
--cvs-exclude, -C        auto-ignore files in the same way CVS does
--filter=RULE, -f        add a file-filtering RULE
-F                       same as --filter='dir-merge /.rsync-filter'
                         repeated: --filter='- .rsync-filter'
--exclude=PATTERN        exclude files matching PATTERN
--exclude-from=FILE      read exclude patterns from FILE
--include=PATTERN        don't exclude files matching PATTERN
--include-from=FILE      read include patterns from FILE
--files-from=FILE        read list of source-file names from FILE
--from0, -0              all *-from/filter files are delimited by 0s
--protect-args, -s       no space-splitting; wildcard chars only
--copy-as=USER[:GROUP]   specify user & optional group for the copy
--address=ADDRESS        bind address for outgoing socket to daemon
--port=PORT              specify double-colon alternate port number
--sockopts=OPTIONS       specify custom TCP options
--blocking-io            use blocking I/O for the remote shell
--outbuf=N|L|B           set out buffering to None, Line, or Block
--stats                  give some file-transfer stats
--8-bit-output, -8       leave high-bit chars unescaped in output
--human-readable, -h     output numbers in a human-readable format
--progress               show progress during transfer
-P                       same as --partial --progress
--itemize-changes, -i    output a change-summary for all updates
--remote-option=OPT, -M  send OPTION to the remote side only
--out-format=FORMAT      output updates using the specified FORMAT
--log-file=FILE          log what we're doing to the specified FILE
--log-file-format=FMT    log updates using the specified FMT
--password-file=FILE     read daemon-access password from FILE
--early-input=FILE       use FILE for daemon's early exec input
--list-only              list the files instead of copying them
--bwlimit=RATE           limit socket I/O bandwidth
--stop-after=MINS        Stop rsync after MINS minutes have elapsed
--stop-at=y-m-dTh:m      Stop rsync at the specified point in time
--write-batch=FILE       write a batched update to FILE
--only-write-batch=FILE  like --write-batch but w/o updating dest
--read-batch=FILE        read a batched update from FILE
--protocol=NUM           force an older protocol version to be used
--iconv=CONVERT_SPEC     request charset conversion of filenames
--checksum-seed=NUM      set block/file checksum seed (advanced)
--ipv4, -4               prefer IPv4
--ipv6, -6               prefer IPv6
--version, -V            print the version + other info and exit
--help, -h (*)           show this help (* -h is help only on its own)

Use "rsync --daemon --help" to see the daemon-mode command-line options.
Please see the rsync(1) and rsyncd.conf(5) man pages for full documentation.
See https://rsync.samba.org/ for updates, bug reports, and answers
rsync error: syntax or usage error (code 1) at main.c(1735) [client=3.2.3]
